ADMT SY Series -High Precision Water Detector

ADMT SY series (Water Detectors) is a new age intelligent prospecting instrument designed for shallow, medium-deep, and deep GroundWater Exploration. It is entirely supported by Mobile Application software for Data Acquisition, processing, and Interpretation that surpasses the limitations of resistivity meters in Ground Water exploration. It uses a mobile phone or tablet PC to execute the complicated information calculated to realize and draw 2D/3D profile maps and contour maps by an application. This innovative advanced technology enables the detailed geophysical survey to become more accessible and simpler.

With the application, you could use many intelligent functions such as field measurement control, instant data process, cloud backup, online expert analysis, bluetooth data transaction, etc. The instrument is connected to the application through the built-in Bluetooth, so you can use the APP to realize all the instrument's operations, such as measurement signal input, data checking, and processing. Wireless sensors can complete all the measurements by walking and stopping, with no need for ground electrodes. No need for long cable, Saving time and workforce.

What is groundwater exploration?

The geoelectric resistivity technique is meant to be the most suitable and efficient way for groundwater exploration. It depends upon the concept of subsurface determination, which can yield valuable data on the structure, composition, and water content of the soil.

The best geophysical survey of groundwater exploration is the seismic survey. Seismic surveys are a beneficial geophysical method for studying the ground conditions to a significant depth and over a large area. Seismic is utilized in many applications for subsurface investigations, mineral exploration being one of them.

Is there any equipment to find groundwater?

Yes, with the help of high precision water detector, experience the power of the first detector in the world to detect underground water that is highly effective. Scan all ground layers to a depth of 1,300 meters and a front range of up to 5,000 meters.

Which is the successful method for groundwater exploration?

Electromagnetic survey methods have been particularly successful in exploration for potable groundwater, measuring salinity levels in aquifers and monitoring coastal saline intrusion, and mapping soil salinity in connection with crop growth.

Configuration:

Mobile App _ Sensor Version

Touch Screen _ Sensor version

Application:

Shallow and Deep Ground Water Prospecting.
Hot Springs identification.

Software Analysis:

2-D Image

3-D Image

3-D Output

Comparison of image in Mobile phone & Table

Research publications

Comparison of well -logging with MT results

Field Results

Successful Result

Features:

Portability: It is light weight, easily portable, intelligent and ease in field survey.
System Design: ADMT device is available in two different variants ; viz Mobile App Device & Touch Screen Device.
Depth variants :It is available in different configuration (corresponding to depth of GW Investigation) .Depth variants include 200m, 300m.
Simple Operation: Unlike Resistivity survey, which require large space for conducting VES sounding, especially for deeper investigation. ADMT Survey requires very limited space for acquiring deeper depth. Hence it effectively solves GW problem in urban area and area with space constraints.
Instant Graphs: Directly drawing the 2D/3D map by the APP after data collection. It has wide application in Hydrogeology to find detailed information such as the direction, depth and output of ground water, greatly improving the success rate of well drilling.
Efficiency: unique wireless prospecting technology, one person can complete all work, saving time and manpower.
Precision: Strong anti-interference ability, field source correction and patent tech to process data.
Online Expert analysis: Online professional expert to help analyze to determine the best drilling location.
Data Protection: Data cloud storage, no need to worry about the data.
Lifetime Validity: Lifetime free upgrade of Mobile app, ensures that device is always up to date , consistent , operating correctly. It reduces the risk of downtime to absolute minimum and enhances survey results to absolute maximum.
Sensor: High-precision electromagnetic sensor is optimized for special anti-noise processing to match the appropriate measurement accuracy. Sensor enables survey in rocky surface, roads, cemented platform with accuracy and success.

Specifications:

Parameter	ADMT-200SY	ADMT-300SY
Measurement Range	0-300mv
Detect Depth	0-200m	0-300m
Measuring	40	60
Model (Intelligent Frequency Select)	frequencies	frequencies
Resolution	1mv	0.5mv
Repetitive Error	±3% ±2bit	±2% ±2bit
A/D Switch	16bit 1Msps
Input Impedance	≥ 10MΩ
Power Frequency Suppression	> 80dB
Data Storage	32GB in U Disk
Display	Mobile display or tablet PC, in-built display 5 inch
Connection Mode	Bluetooth 4.0
Mainframe Power Supply	DC7.4V 3400mAh Lithium battery
Mainframe Power Consumption	360mA	360mA
Operating Temperature	-10℃ ~ +40℃	-20℃~+60℃
Mainframe Size	18.6x14.8x8cm
Mainframe Weight	0.8KG
